60 Series(NEMA24) brushless DC servo motor

60 Series(NEMA24) brushless DC servo motor

Encoder signal waveform



Electrical Specifications



Series   Model

Rated

power

Rated

voltage

Rated    current

Number

of

poles

Rated speed

Rated

torque

Peak

torque

Torque

constant

  Length

Weigh

W

VDC

A


rpm

N.m

N.m

P/R

mm

Kg

60SF3A50-240-1000Z

78

24

4.3

8

3000

0.25

0.75

1000

78

0.9

60SF3A70-440-1000Z

157

48

4.3

8

3000

0.5

1.5

1000

100

1.3

60SF3A90-240-1000Z

235

24

13

8

3000

0.75

2.25

1000

120

1.75

Reverse potential phase sequence diagram


Dimensions


Connection definition


Encoder   lead definition

Power cord


1

2

3

4

5

6

7

8

9

10

11

12

13

14

1

2

3

color

black

red

blue

Yellow-black

green

Green and   yellow

white

White-black

palm tree

Brown   and black

ash

Gray-black

orange

Orange   black

yellow

green

blue

signal

GND

+5V

U+

U-

V+

V-

W+

W-

A+

A+

B+

B-

I+

I-

U

V

W


*We can customize products according to customer requirements
