26HY 2 phase 1.8 degree
• Compact Size for High Torque • NEMA Size 26 Mounting• Custom winding available (No additional cost)• RoHS and CE version
Specifications
Model | Step Angle | Motor Length (mm) | Rated Current (A) | Phase Resistance (Ω) | Phase Inductance (mH) | Holding Torque | Detent Torque(N.cmMax) | Rotor Inertia(g.cm2) | Lead Wire | Motor Weight (g) |
26HY0418 | 1.8 | 13.5 | 0.3 | 20 | 3.2 | 1.2 | 0.2 | 2.5 | 4 | 50 |
Dimensions
