73ZYT Brush DC Motor
73ZYT Brush DC Motor
| Voltage V | Noload | Rated load | Torque Nm | Power W | Length mm | ||
Current A | Speed rpm | Current A | Speed rpm | |||||
73ZYT84135 | 13. 5 | ≤0.6 | 2000±8% | ≤3.8 | 1600±8% | 0.2 | 34 | 84 |
73ZYT9124 | 24 | ≤0. 5 | 1600±8% | ≤2.3 | 1250±8% | 0.25 | 33 | 91 |
73ZYT13012 | 12 | ≤1.03 | 2210±8% | ≤12.6 | 1650±8% | 0.6 | 104 | 130 |
Note: the above is only representative products,
specific shape and performance parameters can be customized according to customer requirements.
