30ZYN Brush DC Motor
30ZYN Brush DC Motor
Model |
Voltage V |
Noload |
Rated load |
Torque Nm |
Power W |
Length mm | ||
Current A | Speed rpm | Current A | Speed rpm | |||||
30ZYN5712 | 12 | ≤0.13 | 3700±8% | ≤0.7 | 3000±8% | 0.015 | 5 | 57 |
30ZYN5724 | 24 | ≤0.07 | 3700±8% | ≤0.35 | 3000±8% | 0.015 | 5 | 57 |
30ZYN6924 | 24 | ≤0.15 | 4400±8% | ≤0.8 | 3700±8% | 0.025 | 10 | 69 |
Note: the above is only representative products,
specific shape and performance parameters can be customized according to customer requirements.
