63ZYT Brush DC Motor
63ZYT Brush DC Motor
Model | Voltage V | Noload | Rated load | Torque Nm | Power W | Length mm | ||
Current A | Speed rpm | Current A | Speed rpm | |||||
63ZYT10624 | 24 | ≤ 0.8 | 3600± 8% | ≤ 9 | 3000± 8% | 0.4 | 125 | 106 |
63ZYT9124 | 24 | ≤ 0.65 | 3500± 8% | ≤ 4.5 | 3000± 8% | 0.2 | 63 | 91 |
63ZYT9624 | 24 | 0.80 | 3800± 8% | ≤ 6.5 | 3000± 8% | 0.3 | 94 | 96 |
63ZYT11324 | 24 | ≤ 1 | 3800± 8% | ≤ 10 | 3000± 8% | 0.45 | 141 | 113 |
63ZYT11324 | 24 | ≤ 1.1 | 4000± 8% | ≤ 11 | 3000± 8% | 0.5 | 157 | 113 |
Note: the above is only representative products,
specific shape and performance parameters can be customized according to customer requirements.
